200 Ton Internal Combustion Aircraft Tow Tractor-DT160
Model: QSF3.8T4C120
Max Drawbar Pull:120kN
Travel Speed (Unloaded):25km/h
Description
The DT160 aircraft tractor is designed specifically for the towing service of small and medium-sized aircraft,and can meet the towing operation of aircraft with a weight less than B767 (including B767).The tractor adopts fully hydraulic four-wheel power steering with four steering modes, with a small turning radius and flexible handling, ensuring maximum safety during use.JEAKUE 200 Ton Internal Combustion Aircraft Tow Tractor-DT160
Safety Protection:
The engine has anti second start function.JEAKUE 200 Ton Internal Combustion Aircraft Tow Tractor-DT160
When the gear is not in neutral, the engine cannot start.JEAKUE 200 Ton Internal Combustion Aircraft Tow Tractor-DT160
The circuit is simple and easy to maintain.JEAKUE 200 Ton Internal Combustion Aircraft Tow Tractor-DT160
Product Features:
The four-wheel drive system ensures the most effective traction capability in various environments.JEAKUE 200 Ton Internal Combustion Aircraft Tow Tractor-DT160
The braking system is a dual line hydraulic braking system. Imported engine with four stage emissions.JEAKUE 200 Ton Internal Combustion Aircraft Tow Tractor-DT160
Convenient and maintainable processing system.JEAKUE 200 Ton Internal Combustion Aircraft Tow Tractor-DT160
Specifications
| Parameter | Value |
|---|---|
| Rated Capacity | 200000kg |
| Min. Ground Clearance | 230mm |
| Overall Length | 5660mm |
| Overall Width | 2200mm |
| Height | 2110mm |
| Wheelbase | 2300mm |
| Towing Coupler Height (F/R) | 430/430mm |
| Turning Radius | 5000/3500mm |
| Service Weight | 15500kg |
| Max Drawbar Pull | 120kN |
| Travel Speed (Unloaded) | 25km/h |
| Model | QSF3.8T4C120 |
| Emission Standard | Tier 4 Final |
