6 Ton(13227.72 lb) Electric Tow Tractor-ET06

Battery:51.2V/519Ah Lithium iron phosphate Battery

Max Drawbar Pull:6000N

Travel Speed (Loaded/Unloaded):9/12km/h

Description

ET06 electric tractor has a compact design structure and a very small turning radius,providing first-class maneuverability. It has the advantages of excellent performance, beautiful appearance, comfortable driving and riding, stable transmission, safety and reliability, high work efficiency, environmental protection and pollution-free, long service life, low noise, high reliability, etc. lt can be widely used for traction operations in any narrow area such as ports, stations, warehouses, etc.JEAKUE 6 Ton Electric Tow Tractor-ET06

Safety Protection

Seat safety switch.JEAKUE 6 Ton Electric Tow Tractor-ET06

Emergency brake switch.JEAKUE 6 Ton Electric Tow Tractor-ET06

Product Features

The entire vehicle is designed with a compact structure, compact and beautiful appearance,small turning radius, and good maneuverability.JEAKUE 6 Ton Electric Tow Tractor-ET06

The parking brake adopts electromagnetic braking method, which is lightweight, fast, reliable, and convenient for maintenance.JEAKUE 6 Ton Electric Tow Tractor-ET06

Powerful power system, precise speed regulation performance, and brake regeneration function, with excellent performance.JEAKUE 6 Ton Electric Tow Tractor-ET06

The inching switch at the rear of the vehicle body has a micro adjustment function, resulting in high work efficiency.JEAKUE 6 Ton Electric Tow Tractor-ET06

Specifications

Parameter Value
Rated Capacity 6000 kg(13227.72lb)
Min. Ground Clearance 140 mm(5.51in)
Overall Length 2085 mm(82.09in)
Overall Width 990 mm(38.98in)
Height 1445 mm(56.89in)
Wheelbase 1170 mm(46.06in)
Towing Coupler Height (Up/Down) 265 / 370 mm(10.43/14.57in)
Turning Radius 1680 mm(66.14in)
Service Weight 1000 kg(2204.62lb)
Max Drawbar Pull 6000 N
Travel Speed (Loaded/Unloaded) 9 / 12 km/h
Max. Gradeability (Loaded/Unloaded) 5 / 10 %
Type Lithium iron phosphate Battery
Voltage/Capacity 51.2V / 519Ah
