4.5 Ton Pedestrian Electric Tow Tractor-ET-450A

Rated Capacity: 4500kg(9920.80lb)
Rated/Maximum traction:1300N
24V120Ah Lithium Battery/Lead-acid Battery

Description

Brand		JEAKUE
Model		ET-450A
Power supply		Electric
Operating type		Pedestrian
Max traction weight	kg	4500
Rated pulling force	N	1300
Wheelbase	mm	770
Truck weight（with battery）	kg	450
Battery weight	kg	70
Tire type,Drive wheel/Bearing wheel		Rubber
Sizes of drive wheel（diameter×width）	mm	2×Φ375×115
Sizes of bearing wheel（diameter×width）	mm	Φ300×100
Sizes of Supporting wheel(diameter×width)	mm	Φ100×50
Drive wheel/bearing wheel number(X=Drive wheel)	mm	2×/1
Front gauge	mm	460
Overall height	mm	1250
Height of tiller in drive position	mm	1100
Hook height	mm	205/315/370
Overall length	mm	1275
Overall width	mm	810
Ground clearance	mm	100
Turning radius	mm	1080
Drive speed load/unload	Km/h	3～6
Rated pulling force	N	1300
Max pulling force	N	2500
Max gradeability load/unload	％	5
Brake type		Electromagnetic
Drive motor rating S2 60min	kw	1.8
Charger(external)	V/A	24/15
K20 Battery voltage/nominal capacity	V/Ah	24/120
Battery weight	kg	70
Type of drive control	kg	AC
Steering type		Mechanics
Noise level		<70
Type of trailer coupling	dB(A)	Latch
