4.5-5.5 Ton Pedestrian Electric Tow Tractor-ET-450/550

Rated Capacity: 4500-5500kg(9920.80-12125.42lb)
Rated/Maximum traction:1300-1800N
24V116/120Ah Lithium Battery/Lead-acid Battery

Description

Brand		JEAKUE	JEAKUE
Model		ET-450	ET-550
Power supply		Electric	Electric
Operating type		Pedestrian	Pedestrian
Max traction weight	kg	4500	5500
Rated pulling force	N	1300	1800
Wheelbase	mm	620	620
Truck weight（with battery）	kg	400	450
Battery weight	kg	70	70
Tire type,Drive wheel/Bearing wheel		PU Rubber/PU	PU Rubber/PU
Sizes of drive wheel（diameter×width）	mm	2×Φ375×115	2×Φ375×115
Sizes of bearing wheel（diameter×width）	mm	Φ150×50	Φ150×50
Drive wheel/bearing wheel number(X=Drive wheel)	mm	2×/1	2×/1
Front gauge	mm	630	630
Overall height	mm	1060	1060
Height of tiller in drive position	mm	1000	1000
Hook height	mm	235/285/335	235/285/335
Overall length	mm	1575	1575
Overall width	mm	810	810
Ground clearance	mm	100	100
Turning radius	mm	1335	1335
Drive speed load/unload	Km/h	3～5	3～5
Rated pulling force	N	1300	1800
Max pulling force	N	2500	3500
Max gradeability load/unload	％	5	5
Brake type		Electromagnetic	Electromagnetic
Drive motor rating S2 60min	kw	1.8	2
Charger(external)	V/A	24/15	24/15
K20 Battery voltage/nominal capacity	V/Ah	24/116	24/120
Battery weight	kg	70	70
Type of drive control	kg	AC	AC
Steering type		Mechanics	Mechanics
Noise level		<70	<70
Type of trailer coupling	dB(A)	Latch	Latch
