Description

Explore the FB250MH

With its 618V high-voltage Li-ion system and robust 135 kW PMSM motor, the FB250MH sets a new standard in the high-capacity forklift segment. Capable of lifting 25,000 kg at a 1,200 mm load center, it combines diesel-like power with electric precision. Designed for maximum uptime, the truck features advanced thermal management, high-grade hydraulics, and a full AC cabin for operator comfort and safety.
1.High Performance: High speed and high gradeability

High-voltage Li-ion batteries enable more power delivery to motors, improving acceleration and travel speeds for high-capacity trucks. PMSMs complement this with rapid response times, swiftly reaching required speeds and torques. This combination of PMSM and high voltage can provide stable and strong power output, which further gives high-capacity trucks excellent climbing capabilities ensuring that the forklift can cope with various applications with ease. The high-voltage model offers a 1.5-2 times performance improvement over the low-voltage model. Taking the 10-ton model as an example: 100% improvement in travel speed for high voltage models in laden and unladen conditions. The high-voltage model demonstrates a 45% faster lifting speed. 100% improvement in gradeability when unladen, 45% improvement when laden for high voltage models.

2.Energy Efficiency: extended runtime and fast charging

High-voltage Li-ion batteries have high energy density and can store more electrical energy within a compact volume. High-voltage systems consume less energy and provide longer battery running time comparing low-voltage systems. Notably, these high-voltage Li-ion batteries boast an impressive cycle life of up to 4000 cycles, ensuring long-term durability and minimizing the need for battery replacements. The PMSMs incorporate advanced control technology to optimize motor efficiency. Unlike traditional AC motors, PMSMs have higher energy conversion efficiency and reduce energy waste. This means that high-capacity trucks can work continuously for prolonged hours at lower costs. Equipped with fast charging capabilities, high-capacity trucks offer a remarkable charging experience. The high-voltage models are compatible with vehicle-grade charging stations and support 1C charging rating, allowing them to be fully charged in as fast as 1-1.2 hours. This minimizes downtime and maximizes productivity, making it ideal for multi-shift operations Lithium batteries present considerably lower charging costs than fuel expenses. The integration of high-voltage and PMSM technology achieves up to 15% greater electricity savings versus traditional lithium and AC technology configurations. This significantly reduces long-term energy consumption costs.

3.Safety Assured: Battery, motor protection, monitoring and mast buffering

Both high-voltage lithium batteries and PMSM employ multiple protective measures to ensure safe operations including overcharge protection, over-temperature monitoring, short-circuit protection, etc. minimizing the risk of potential hazards and maximizing operational safety. The central controlling module- VCU (Vehicle Control Unit) extends the safety of the high-voltage forklifts. VCU provides precise control and real-time monitoring of critical parameters to ensure the truck operates within safe limits. It also features turn speed control, which adjusts the forklift’s speed based on the turning angle, ensuring stability during turns. An over-speed alarm alerts the operator if the forklift exceeds the safe speed limit.* The high-capacity forklift mast is equipped with a hydraulic buffering system that ensures smooth lifting and lowering of loads. With controlled deceleration, the fork movement is smooth with no abrupt stops that could damage the load or cause operator discomfort. This feature enhances operational safety and prolongs the lifespan of the mast components.

4.Smart and reliable strategy for thermal management

The high-capacity trucks utilize three distinct cooling systems to ensure optimal performance and reliability. Specifically, two water cooling systems are employed for the motor and the battery, while an oil cooling system is dedicated to the hydraulics system. The water cooling systems provide superior cooling performance, preventing the truck from overheating even under the most demanding conditions or in the heat of summer. Water’s higher heat transfer capacity compared to air allows it to dissipate heat more efficiently from critical components like the motor and battery. This efficient heat dissipation helps maintain the battery temperature around 30~35℃, protecting these vital components from overheating and potential damage or failure. Consequently, this enhances the overall reliability and longevity of the high-capacity trucks. Additionally, water cooling systems typically operate with less noise compared to air cooling systems that rely on high-speed fans. This noise reduction is particularly beneficial in applications where a quieter operation is desirable, such as in urban areas or indoor facilities. The oil cooling system, on the other hand, is used for the hydraulics system. This system ensures that the hydraulic components remain within optimal temperature ranges, thereby maintaining their efficiency and preventing overheating. By effectively managing the temperature of the hydraulics system, the oil cooling system contributes to the smooth and reliable operation of the truck’s hydraulic functions.

5.Low maintenance: Longer battery life span

Operating at a higher voltage allows the battery to be designed with fewer individual cells. With fewer components and a simpler design, the risk of battery failure is lowered. Thanks to advanced BMS (Battery Management System) which helps to regulate and monitor high-voltage battery, these batteries tend to have a longer life than low-voltage lithium batteries, reducing the need of battery replacement. The brushless, simple rotor design of PMSM eliminates mechanical wear from brushes and commutators. This durable, low-friction construction requires minimal periodic maintenance, reducing associated labor costs and downtime.

6.Sustainability : Zero emissions for cleaner environment

As fully electric trucks powered by lithium-ion batteries, these forklifts produce zero emissions during operation, eliminating exposure to toxic fumes like carbon monoxide and nitrogen oxides. Unlike lead-acid batteries which can leak corrosive acid, lithium-ion batteries do not risk hazardous spills. The high-capacity li-ion trucks contribute to a cleaner and safer indoor working environment without compromising handling capabilities.

7.Strong adaptability adaptable to harsh outdoor weather conditions

Experience uninterrupted productivity through rain, puddles, and damp conditions with the overall IPX4 rating. Plus an exceptional IP67 rating for high-voltage components. Engineered to withstand harsh temperature, high-capacity trucks offer an ambient temperature range of -20℃~40℃ allowing them to perform no matter climate. Battery heating when charging comes as a standard function for high capacity models, which is activated when the surrounding temperature is below zero to always offer an optimal temperature range for efficient and safe charging even in cold weather conditions. The dual front wheels is a standard configuration on several models offering a wider base of support, which greatly improves the forklift’s stability. Considering the capacity loads of the high-capacity trucks, the weight of the load is more evenly distributed across a larger surface area. The increased ground contact area provided by the dual wheels enhances traction. This is particularly beneficial in environments where the floor may be slippery or uneven while operating outdoors, ensuring that the forklift can maintain a firm grip and operate safely. This not only helps in maintaining balance but also minimizes the stress on individual tires, extending the lifespan of the tires.

8.Great support for clients’ investment: After-sales Service

Remote/Online Services: Telematics technology enables remote monitoring of battery conditions, performance status, and other critical parameters for forklifts. Additionally, production, technical, and after-sales experts are available around the clock to provide prompt and comprehensive solutions for any maintenance issues through virtual support. Physical Services: Comprehensive manuals and supporting documents are provided for all forklift models. In case of breakdowns or replacements, spare parts are swiftly delivered to the clients’ locations by global subsidiaries or domestic inventory, minimizing operational disruptions caused by equipment downtime.

Application

With its 618V high-voltage Li-ion system and robust 135 kW PMSM motor, the FB250MH sets a new standard in the high-capacity forklift segment. Capable of lifting 25,000 kg at a 1,200 mm load center, it combines diesel-like power with electric precision. Designed for maximum uptime, the truck features advanced thermal management, high-grade hydraulics, and a full AC cabin for operator comfort and safety.

About the FB250MH

The FB250MH is the most powerful member of JK’s heavy-duty Li-ion lineup. Powered by a 618V/456Ah LFP battery, it delivers superior torque, long runtime, and fast charging with minimal maintenance. Dual PMSM motors — 135 kW drive and 90 kW lift — ensure rapid response and efficient energy use.

The integrated cooling system combines water cooling for motor and battery with oil cooling for hydraulics, ensuring consistent temperature control during continuous operations. Its hydraulic braking system and OPS-equipped ergonomic cabin guarantee safe, precise handling even under full load.

Operators benefit from a spacious, air-conditioned cabin, Grammer suspension seat, and fingertip control system for smooth and fatigue-free operation. The FB250MH also includes LED lighting, camera assistance, and telematics options for total control and safety. Combining extreme capacity with sustainability, it provides a true zero-emission alternative to traditional diesel heavy forklifts.

FAQs

What is the maximum load capacity and lifting performance of the FB250MH?

The FB250MH offers an impressive 25-ton lifting capacity with a 1,200 mm load center and a maximum lift height of 4,000 mm. Powered by a 135 kW drive motor and 90 kW lift motor, it delivers strong acceleration and smooth, high-precision load handling.

How does the 618V Li-ion system improve performance compared to lower-voltage models?

The 618V/456Ah Li-ion battery ensures higher energy efficiency by reducing current draw and heat generation. This results in faster power delivery, longer runtime, and improved system reliability. The high-voltage platform also supports rapid opportunity charging for continuous operation in demanding applications.

Is the FB250MH suitable for outdoor and heavy industrial environments?

Yes. With a rugged IC-style chassis, pneumatic tires, and 220 mm ground clearance, the FB250MH performs reliably on uneven or rough terrain. Its IPX4-rated components and oil- and water-cooled systems ensure consistent performance in all-weather conditions, making it ideal for ports, steel mills, and construction sites.

What comfort and safety features does the FB250MH provide for operators?

The truck features a fully enclosed, air-conditioned cabin with wide visibility, LED work lights, and a rearview camera for safe maneuvering. The Grammer suspension seat, fingertip hydraulic controls, and OPS presence system ensure comfort, ergonomics, and top-level safety during long shifts.

How does the FB250MH reduce operating costs compared to diesel forklifts?

The FB250MH eliminates fuel expenses and engine maintenance associated with diesel models. Its Li-ion battery is maintenance-free and supports fast opportunity charging, significantly lowering total cost of ownership while providing consistent, emission-free power for continuous operations.

PRODUCT FEATURES

Load Capacity	25000Kg(50000 lb)
Battery	618.24V228AH Lithium Battery
Controller/Motor	AC
Lift Height	4000mm(157.48in)
Turning Radius	6350mm(250.00in)
Fork Dimensions	110x250x2400mm(4.33×9.84×94.49in) (sxexl)
Steering Design	Hydraulic
Tyre Type	Pneumatic tyre
Service Weight	38700Kg(85318.90lb)
Product Color	Ivory/Ochre/Customization

16–25 Ton Four Wheel High-Voltage Lithium Battery Forklift

Product Features JEAKUE 25 Ton High-voltage Lithium Battery Electric Forklift-250MH

Stable and Reliable

Adopts a box-type welded structure, providing the frame with enhanced structural strength.JEAKUE 25 Ton High-voltage Lithium Battery Electric Forklift-250MH

Box-type Structure JEAKUE 25 Ton High-voltage Lithium Battery Electric Forklift-250MH

Welding Method / Welding Technique

Fast Charging JEAKUE 25 Ton High-voltage Lithium Battery Electric Forklift-250MH

Fast charging technology: fully charged in 1.2 hours, providing 6–7 hours of operation.JEAKUE 25 Ton High-voltage Lithium Battery Electric Forklift-250MH

High-Voltage Power Supply

Provides output current for fuses and heavy-load DO, with feedback to the VCU. The main display screen clearly shows the current load and branch circuit status.JEAKUE 25 Ton High-voltage Lithium Battery Electric Forklift-250MH
