Description

Explore the ES10/12

Available in 1000 kg and 1200 kg versions, the ES10/12 Series offers efficient stacking with lift heights up to 1.6 m. Thanks to the slim mono mast design, operators benefit from enhanced visibility and safe load handling. Compact dimensions (800 mm width and turning radius under 1.3 m) make these stackers ideal for narrow aisles and backroom operations. Powered by maintenance-free AGM batteries with onboard charger, the ES10/12 Series provides cost-effective and reliable daily use .
1.Slim mono mast design

The ES10/12 Series is equipped with a mono mast that reduces weight and offers operators better forward visibility. This design makes handling simpler and safer, especially in low stacking operations.

2.Compact and space-saving chassis

With an 800 mm chassis width and a turning radius of just 1295 mm, the ES10/12 stackers are tailored for narrow aisles, retail backrooms, and tight warehouse layouts where maneuverability is crucial.

3.Low-maintenance energy solution

Powered by AGM batteries with a 24V/85Ah configuration and an onboard charger, the ES10/12 Series ensures easy daily charging, reliable performance, and minimal maintenance. Optional Li-ion battery versions are also available.

4.Operator safety and ease of use

Featuring electromagnetic braking, creep speed mode, and an ergonomic tiller, the ES10/12 Series provides smooth, controlled, and safe operation, even for inexperienced operators.

Application

The ES10/12 Series is designed for light-duty applications in retail, workshops, and warehouses where space optimization and simple stacking are required. With excellent maneuverability, they are perfect for moving and lifting pallets in tight storage areas, such as small shops or auxiliary warehouses. The mono mast structure not only improves visibility but also reduces total weight, making the trucks easy to handle and highly efficient for short stacking cycles.

About the ES10/12

The ES10/12 Series represents JEAKUE’s entry-level solution for stacking. Compact, robust, and simple to operate, these electric stackers combine safety and practicality at an affordable cost. Standard features include polyurethane wheels, ergonomic tiller with crawl speed, and electromagnetic braking for operator confidence. With their mono mast and integrated charger, the ES10/12 Series minimizes maintenance and training needs, making them a perfect first choice for businesses stepping into electric material handling. Optional configurations include different fork dimensions, battery capacities, and mast heights, allowing adaptation to various customer demands.

FAQs

What is the load capacity of the ES10/12 Series?

The series offers two main versions: the ES10 with 1000 kg capacity and the ES12with 1200 kg capacity, both designed for light-duty stacking.
How high can the ES10/12 stackers lift?

The mono mast versions provide lift heights up to 1.6 m, making them suitable for low-rack applications, backroom logistics, and workshop environments.
What type of batteries power the ES10/12 Series?

The trucks come with 24V/85Ah AGM maintenance-free batteries and an integrated charger for simple daily use. Optional Li-ion battery versions are available for greater efficiency and zero maintenance.
Are the ES10/12 stackers suitable for narrow warehouse spaces?

Yes. With a slim 800 mm chassis and a tight turning radius of just 1295 mm, the ES10/12 Series is optimized for small shops, retail backrooms, and warehouses with narrow aisles.
What safety features are included in the ES10/12 Series?

Standard safety features include electromagnetic braking, creep speed mode for precise maneuvering, and an ergonomic tiller design, ensuring safe operation even for inexperienced operators.

PRODUCT FEATURES

Load Capacity	1000Kg(2204.62lb)
Fork Dimensions	1150/170/60mm(45.28/6.69/2.36in)(l x e x s)
Distance Between Fork-arms	550mm(550mm)
Battery Voltage/Nominal Capacity	24V85Ah lead-acid battery
Turning Radius	1295mm(50.98in)
Lift Height	1520mm(59.84in)
Steering Design	Mechanical
Service weight	462Kg(1018.54lb)
Product Color	Ivory/Red/Customization
