1.5Ton Rough Terrain Electric Pallet Truck-ET-150NO

Rated Capacity:1500kg(3306.93lb)

Lift Height:235mm(9.25in)

2×12V86Ah Lithium Battery/Lead-acid Battery

Description

Brand		JEAKUE
Model		ET-150NO
Power supply		Electric
Operating type		Pedestrian
Max traction weight	kg	1500
Rated pulling force	N	500
Wheelbase	mm	1020
Truck weight（with battery）	kg	460
Battery weight	kg	50
Tire type,Drive wheel/Supporting wheel		Rubber
Sizes of drive wheel（diameter×width）	mm	Φ300×100
Sizes of bearing wheel（diameter×width）	mm	2×Φ375×105
Drive wheel/Supporting wheel number(X=Drive wheel)	mm	2×/2
Overall height	mm	1285
Height of tiller in drive position	mm	1010
Lifting height	mm	235
Overall length	mm	1835
Overall width	mm	930
Ground clearance	mm	100
Fork dimensions	mm	1070
Fork width	mm	630
Turning radius	mm	1445
Drive speed load/unload	Km/h	3.5～5.5
Lift speed load/unload	Mm/S	90/120
Lowering speed load/unload	Mm/S	125/80
Max gradeability load/unload	%	5/8
Brake type		Electromagnetic
Drive motor rating	kw	AC1.6
Lift motor rating	kw	DC0.8
K20 Battery voltage/nominal capacity	V/Ah	2×12/86
Battery weight	kg	50
Type of drive control		AC
Steering type		Mechanics
Noise level	dB(A)	<70
