3 Ton(6613.87lb) Diesel Wheel Loader-ZL936

Rated Load:3000kg(6613.87lb)

Lifting Height:3000mm(118.11in)

Bucket rated capacity:1.7 m³(60.03ft³)

Description

Performance	Rated load	3000kg
	Overall weight	10400kg
	Rated bucket capacity	1.7m³
	Maximum tractive force	98KN
	Maximum breakout force	≥127KN
	Maximum grade ability	30º
	Maximum dump height	3000mm
	Maximum dump reach	1260mm
	Overall dimension (L×W×H)	7690×2340×3235mm
	Minimum turning radius	5380mm
Engine	Model	Weichai DEUTZ WP6G125E322
	Type	lnline、 water cooling、 dry cylinder、 injection
	No. of cylinder-bore/stroke	6-108×130mm
	Rated power	92kw–2200r/min
	Maximum torque	515N.m
	Min fuel-consume ratio	≤215g/kw.h
Transmission system	Torque converter	YJ315
	Gearbox mode	Power shift normally engaged straight gear
	Gear shift	4 forward shift 2 reverse shift
	Maximum speed	38km/h
Drive axles	Main reducing spiral	bevel gear grade 1reduction
	Decelerating mode	planetary reduction,grade 1
	Wheel base (mm)	2860mm
	Wheel tread	1990mm
	Minimum ground clearance	360mm
hydraulic system	System working pressure	17MPa
	Boom lifting time	4.83s
	Total time	9.15±0.5s
	Fuel tank capacity	156L
	Function of leveling automatically	yes
Brake system	Service brake	air over hydraulic disc brake on 4 wheels
Brake system	Parking brake	manual parking brake
Tyre	Type specification	17.5-25
	Front tyre pressure	0.4Mpa
	Rear tyre pressure	0.35Mpa
