Description

Explore the RPL201

The RPL201 combines a 2000 kg load capacity with a compact 1806 mm turning radius, making it efficient for heavy-duty material handling. Equipped with a maintenance-free 24V/205Ah Li-ion battery and external charging plug, it supports opportunity charging with zero downtime. Safety features include proportional electric steering with automatic speed reduction in turns, enhanced counterweight stability, and reinforced operator protection.
1.Heavy-duty ride-on design

Equipped with a foldable suspended platform and sidearms, the RPL201 is built for long-distance, high-intensity operations. The platform design reduces operator fatigue while ensuring comfort and safety during extended shifts.

2.Powerful Li-ion technology

Powered by a 24V/205Ah maintenance-free Li-ion battery, the truck supports rapid and opportunity charging through an external plug. This eliminates downtime and maximizes productivity across multi-shift operations.

3.Enhanced travel stability

A lowered center of gravity, repositioned stabilizing wheels, and optimized counterweight provide smooth and stable driving behavior. Automatic speed reduction during turns further enhances operator and load safety.

4.Operator-focused ergonomics

With proportional electric steering, ergonomic tiller, and improved fork tip visibility, the RPL201 ensures precise maneuverability. Integrated storage and reinforced back cover protection add convenience and durability for daily use.

Application

Ideal for heavy-duty, long-distance transport in warehouses and logistics hubs, the RPL201 ensures smooth operation in demanding conditions. Its foldable suspended platform and protective sidearms allow comfortable ride-on use, while creep speed control and ergonomic steering make it equally efficient in confined areas. Suitable for distribution centers, loading docks, and large storage facilities requiring continuous pallet movement.

About the RPL201

The RPL201 redefines long-distance pallet transport with its high-performance Li-ion system and heavy-duty ride-on design. Operators benefit from enhanced driving comfort, precise proportional steering, and improved visibility thanks to the carved battery cover.

Counterweights and stabilizing wheels ensure superior travel stability, while automatic cornering speed reduction increases safety. With options for fork lengths, cold storage adaptation, and weighing system integration, the RPL201 is a versatile solution for demanding supply chains.

FAQs

What is the load capacity of the RPL201?

The RPL201 supports up to 2000 kg, making it suitable for heavy-duty and long-distance transport tasks in warehouses and logistics hubs.
What type of battery powers the RPL201?

It is equipped with a 24V/205Ah Li-ion battery, which is maintenance-free and supports fast opportunity charging via an external plug, ensuring maximum uptime.
How does the RPL201 improve operator comfort?

The truck features a foldable suspended platform, protective sidearms, and ergonomic proportional steering, reducing operator fatigue during long shifts.
Is the RPL201 safe for high-speed operation?

Yes. It includes stabilizing wheels, optimized counterweight design, and automatic speed reduction when cornering, ensuring stability and safety during travel.
Are there customization options available for the RPL201?

Yes. Options include different fork lengths, cold storage configuration, and integration of a weighing system, allowing businesses to adapt the truck to their specific operational needs.

PRODUCT PARAMETERS

Load Capacity	2T(4409.24 lb) Electric Pallet Truck
Fork Dimensions:	1150/150/55mm(45.28/5.91/2.17in)(lxexs)
Distance between fork-arms:	685/540mm(26.97/21.26in）
Battery Voltage/Nominal Capacity:	24V280Ah lithium battery
Turning Radius:	1806mm(71.10in）
Lift Height：	120mm(4.72in)
Steering Design:	Mechanical
Service Weight	755Kg(1664.49lb)
Product Color	Ivory/Red/Customization
Travel Speed, Laden/Unladen	7.5/8 km/h
Max Gradeability, Laden/Unladen	8/16 %
Motor power	1.6KW

1 Precision Upgrade JEAKUE 2T Ride-on Electric Pallet Truck

The fork legs are processed by a special custom boring machine, which effectively guarantees the spacing and dimensional accuracy of the fork legs.

2 Long Connecting Rod Upgrade JEAKUE 2T Ride-on Electric Pallet Truck

Upgraded to high-strength alloy steel welding type, say goodbye to breakage

3 Wear-resistant bushing JEAKUE 2T Ride-on Electric Pallet Truck

The new design of the pin bushing and pin shaft reduces the mutual biting wear.

The four-link structure is upgraded to a double-link structure, which enhances driving stability

4 Double string rod structure JEAKUE 2T Ride-on Electric Pallet Truck

Double string rod structure, small gap, strong impact resistance!

5 Maintenance-free bushings are selected JEAKUE 2T Ride-on Electric Pallet Truck

JEAKUE 2T Ride-on Electric Pallet Truck Grease fittings disappear

JEAKUE 2T Ride-on Electric Pallet Truck Reduce bolt dead angles and make disassembly easier

JEAKUE 2 Ton Lithium Battery Ride-on Electric Pallet Truck-RPL201 Replace the set screw with a spring pin
