Description

Explore the KPL201

The KPL201 combines a 2000 kg load capacity with high maneuverability thanks to its power steering and compact design. Powered by a 24V/205Ah Li-ion battery and supported by a 100A external charger, it delivers fast charging, zero maintenance, and reliable performance for multi-shift usage. With a turning radius of 2217 mm and automatic cornering speed reduction, it ensures safe and efficient material handling.
1.Power steering for effortless control

Equipped with advanced power steering, the KPL201 ensures precise and stable maneuvering. Operators can handle loads with greater efficiency and less effort, even in demanding, high-traffic environments.

2.Li-ion battery efficiency

The 24V/205Ah Li-ion battery with 100A external charger supports rapid opportunity charging and eliminates the need for maintenance. This allows maximum uptime and continuous operation across multi-shift logistics tasks.

3.Operator comfort and safety

Featuring a suspended platform, padded backrest, and semi-enclosed compartment, the KPL201 provides fatigue-free working conditions while ensuring protection against impacts and obstacles.

4.Safe and stable performance

With a lowered center of gravity and automatic speed reduction during turns, the KPL201 enhances travel stability and safety. Its compact chassis and ergonomic design make it highly suitable for both long-distance transport and confined warehouse spaces.

Application

Designed for distribution centers, warehouses, and logistics hubs, the KPL201 is suitable for heavy-duty pallet transport over long distances. Its suspended operator platform, padded backrest, and ergonomic tiller make it comfortable for extended use. The truck’s stability and compact chassis allow it to perform efficiently in narrow aisles and high-intensity operations.

About the KPL201

The KPL201 represents JK’s dedication to reliable and efficient material handling. With its Li-ion battery technology, robust steel chassis, and ergonomic operator compartment, it delivers endurance and operator protection in every shift.
Standard features like power steering, automatic speed reduction when turning, and adjustable tiller height increase both safety and productivity. Optional configurations such as multiple fork lengths, different wheel materials, and cold storage adaptations make the KPL201 a versatile solution for modern supply chains.

FAQs

What is the maximum load capacity of the KPL201?

The KPL201 can handle up to 2000 kg, making it suitable for heavy-duty transport tasks in warehouses and logistics hubs.
What type of battery does the KPL201 use?

It is powered by a 24V/205Ah Li-ion battery, paired with a 100A external charger for fast opportunity charging and zero maintenance.
How does the KPL201 improve operator comfort?

The truck features a suspended platform, padded backrest, and ergonomic tiller, providing a comfortable and safe working environment during long shifts.
Is the KPL201 safe for high-intensity warehouse use?

Yes. It includes power steering for stable maneuvering, automatic speed reduction during cornering, and a compact chassis design to improve stability and safety in busy or narrow areas.
Are there customization options available for the KPL201?

Yes. Options include different fork lengths, wheel materials, and cold storage adaptations, allowing businesses to tailor the truck to their specific needs.

PRODUCT PARAMETERS

Load Capacity	2T(4409.24 lb) Electric Pallet Truck
Fork Dimensions:	1150/170/55mm(45.28/6.69/2.17in)(lxexs)
Distance between fork-arms:	685mm(26.97in)
Battery Voltage/Nominal Capacity:	24V205Ah Lithium Battery 24V280Ah Lead-acid Battery
Turning Radius:	2217mm(87.28in)
Lift Height：	125mm( 4.92in)
Steering Design:	Mechanical
Service Weight	785/838Kg(1730.63/1847.47lb)
Product Color	Ivory/Red/Customization
Travel Speed, Laden/Unladen	8.5/10 km/h
Max Gradeability, Laden/Unladen	6/16 %
Motor power	1.6KW



Adjustable operating mode,Customize your operating habits
Comfortable backrest designEasier operation Emergency stop pedal, safer operation

JEAKUE 2 Ton Ride-on Electric Pallet Truck-KPL201

High-performance system

High-performance drive system provides strong power; more precise control and smoother operation;
High-strength vertical gearbox, Extremely long working life;

High-quality accessories

JEAKUE 2 Ton Ride-on Electric Pallet Truck-KPL201

Reliable American AMP waterproof connectors and electrical components, all wires and cables are reliably protected and fixed, greatly reducing electrical failures;

Emergency braking function prevents the operator from getting hurt;

JEAKUE Anti-skid braking function prevents the vehicle from sliding down when it loses control or is driving on a slope;

The emergency power-off switch can easily cut off all power to avoid emergency accidents when the operation is out of control;
The anti-skid braking function prevents the car from sliding down when it is out of control or driving on a slope;

JEAKUE 2 Ton Ride-on Electric Pallet Truck-KPL201

Easy maintenance
Timer and power meter are configured to remind the operator to charge in time and protect the battery; the machine body is easy to disassemble and assemble.By opening the mask, the main key components can be inspected, repaired and replaced; the
controller self-diagnosis system displays the fault code through the handheld unit, making it easier to solve the fault. Low voltage
protection prolongs the battery life.

JEAKUE 2 Ton Ride-on Electric Pallet Truck-KPL201
