2 Ton(4409.24lb) Diesel Wheel Loader-ZL936CZ

Rated Load:2000kg(4409.24lb)

Lifting Height:3310mm(130.31in)

Bucket rated capacity:1 m³(35.31ft³)

Description

Performance	Rated load	2000kg
	Overall weight	5600kg
	Rated bucket capacity	1m³
	Maximum tractive force	61KN
	Maximum breakout force	≥72KN
	Maximum grade ability	30°
	Maximum dump height	3310mm
	Maximum dump reach	1000m
	Overall dimension (L×W×H)	6100×2080×2930mm
	Minimum turning radius	5600mm
Engine	Model	YN 4102 turbo engine
	Type	inline 、 water cooling 、dry cylinder、 injection
	No. of cylinder-bore/stroke	4-102×115mm
	Rated power	76kw–2400r/min
	Maximum torque	280N.m
	Min fuel-consume ratio	≤225g/kw.h
Transmission system	Torque converter	YJ265
	Gearbox mode	Power shift normally engaged straight gear
	Gear shift	4 forward shift, 4 reverse shift
	Maximum speed	30km/h
Drive axles	model	Medium hub reduction axle
	Decelerating mode	planetary reduction,grade 1
	Wheel base (mm)	2520mm
	Wheel tread	1560mm
	Minimum ground clearance	320mm
hydraulic system	System working pressure	16MPa
	bucket lifting time	≤5s
	bucket falling time	≤4s
	Total time for a single working cycle	≤10.5s
	Function of leveling automatically	yes
Brake system	Service brake	air over hydraulic disc brake on 4 wheels
Brake system	Parking brake	manual parking brake
Tyre	Type specification	16/70-20
	Front tyre pressure	0.4Mpa
	Rear tyre pressure	0.35Mpa
