Description

Explore the FBR15S

The FBR15S stand-up reach truck delivers reliable stacking performance with a rated capacity of 1.5 tons and lift heights up to 7.5 meters. Its stand-on design ensures a broader view for operators, while the combination of electric power steering, ergonomic controls, and polyurethane wheels provides stable, smooth, and efficient handling in space-constrained warehouses.
1.Compact stand-up design

The stand-on configuration provides operators with a wider view and excellent maneuverability, enabling safe and efficient stacking in narrow aisles and high racking environments.

2.Stable and precise lifting

With lift heights up to 7.5 meters and a rated capacity of 1.5 tons, the FBR15S maintains stability through its non-floating drive system, ensuring consistent performance at maximum height.

3.High-quality global components

Equipped with premium parts such as a USA KDS motor, Japan Shimadzu pump, Italy ZAPI controller, and USA AMP connectors, the FBR15S guarantees reliability, long service life, and smooth performance in intensive applications.

4.Efficient Li-ion ready power system

Powered by a 48V/420Ah battery (with optional capacities up to 465Ah or Li-ion packs), the FBR15S supports long shifts, quick recharging, and reduced maintenance. This ensures flexibility and efficiency in demanding multi-shift operations.

Application

The FBR15S is ideal for warehouses, logistics hubs, and distribution centers with narrow aisles and high racking systems. It ensures precise and efficient stacking even in confined spaces, supported by a non-floating drive system that enhances stability at high lifting positions. Its stand-up design improves visibility and maneuverability, making it a strong choice for operations where space utilization and operator efficiency are critical.

About the FBR15S

The FBR15S combines advanced technology and high-quality components from global suppliers—including a USA KDS motor, Japan Shimadzu pump, Italy ZAPI controller, and USA AMP connectors—for reliable and durable performance. With travel speeds of up to 9 km/h and lift speeds of 0.44 m/s (unladen), it maximizes operational efficiency. The 48V/420Ah battery ensures long runtime with optional capacities up to 465Ah, while electromagnetic braking and electronic steering improve safety and control. With mast options extending up to 7.5 m, cold storage configurations, and optional features such as LED lamps, warning systems, and telematics, the FBR15S is a versatile and future-ready reach truck solution for modern warehouses.

FAQs

What is the load capacity of the FBR15S?

The FBR15S has a rated load capacity of 1.5 tons, making it suitable for medium-duty stacking and retrieval in warehouses.

How high can the FBR15S lift?

The truck offers lift heights up to 7.5 meters, providing reliable performance for high-racking operations.

What type of power system does it use?

It is powered by a 48V/420Ah battery, with optional higher-capacity batteries (up to 465Ah) and Li-ion configurations available for extended runtime and fast charging

Why is the stand-on design beneficial?

The stand-up configuration gives operators better visibility, agility, and control in narrow aisles, while also improving comfort during frequent entry and exit cycles.

What components ensure reliability and durability?

The FBR15S is equipped with high-quality components from leading global suppliers, including a USA KDS motor, Japan Shimadzu pump, Italy ZAPI controller, and USA AMP connectors.

PRODUCT PARAMETERS

Load Capacity	15000kg(3306.93 lb) Ride-on Reach Forklift Truck
Battery	48V300Ah/345Ah/360Ah/420Ah/450Ah/465Ah Lead-acid Battery
Controller/Motor	AC
Lift Height	3000-7500mm(118.11-295.28in)
Turning Radius	1765mm(69.49in)
Dimensions	3020*1170*2078mm(118.90*46.06*81.81in)
Steering Design	Electric Powering Steering
Tyre type	Polyurethane tyre
Service weight	2370kg(5224.96lb）
Product Color	Ivory/Red/Customization

1 High performance, high reliability JEAKUE 1.5 Ton Ride-on Reach Forklift Truck
AC drive system provides strong power, more precise control and smoother operation;
High-strength vertical gearbox,ultra-long working life;
The oil pump, oil cylinder and pipelines that have undergone multiple layers of testing ensure the high reliability of the hydraulic system;
Reliable quality American AMP waterproof connectors and electrical components, all wires and cables are reliably protected and fixed,

JEAKUE 1.5 Ton Ride-on Reach Forklift Truck
The design of super-large high-strength load-bearing wheels ensures the stability of the whole vehicle;
High-efficiency heat dissipation system (supports long-term continuous work):JEAKUE
The floating drive wheel design ensures that it is suitable for a variety of working conditions with uneven roads.

2 Safer JEAKUE 1.5 Ton Ride-on Reach Forklift Truck
The explosion-proof design of the hydraulic system ensures that even if the oil pipe bursts,the mast will not drop quickly,
thus improving safety;
Automatic deceleration function on curves, safer driving (electric steering):
Emergency power off switch can easily cut off all power supply in case of out-of-control operation to avoid emergency accidents;
Multiple lifting limits make stacking safer;JEAKUE
Anti-skid braking function prevents the car from sliding down when it is out of control or driving on a slope;
JEAKUE 1.5 Ton Ride-on Reach Forklift Truck
Dual-channel monitoring electronic steering, safe and reliable (electric steering).

3 Easy to operate JEAKUE 1.5 Ton Ride-on Reach Forklift Truck
The control panel fully considers ergonomics, and each function button is easy to operate;
The driving position is equipped with a backrest and seat support,making driving more comfortable;
Spacious driving space design significantly improves driving comfort;JEAKUE
JEAKUE Reach Forklift Truck Compact design, flexible and free driving:
The battery can be pulled out in one action, making it easy to replace the battery and convenient for continuous operation;
Electronic steering, easier to operate (electric steering).JEAKUE

4 JEAKUE 1.5 Ton Ride-on Reach Forklift Truck
AC motor, maintenance-free JEAKUE Reach Forklift Truck;
Instruments that can display fault codes greatly facilitate repair and maintenance;
Fully open maintenance space,convenient for inspection,maintenance and replacement of parts;JEAKUE
The use of vertical motors makes the inspection and maintenance of motors and brakes more direct and convenient,

JEAKUE Reach Forklift Truck the maintenance performance is much better than that of horizontal motors;
JEAKUE Reach Forklift Truck Controller self-diagnosis system;
Automatic low voltage protection to extend battery life
